Husqvarna P525DX Commercial Ride on Front Mower Diesel

Description

HUSQVARNA P525DX COMMERCIAL RIDE ON FRONT MOWER DIESEL

High-capacity diesel-powered front mower offering unbeatable manoeuvrability and productivity in complex and narrow environments as well as in larger-sized areas. The commercial graded transmission gives uncompromised traction and slope stability. The machine’s compact size and high transport speed makes it suitable both for stationary and mobile application for municipalities, contractors, housing agencies etc. Thanks to the front-mounted cutting deck the operator has perfect overview of the working area. This means optimised trimming ability as well as accessibility under benches, bushes etc. Long-life components for solid durability and less downtime. Attachments such as utility bucket, broom, folding plough and cabin give increased productivity all-year round. Husqvarna P 525DX is delivered deckless and can be fitted with 132 and 155 cm Combi cutting decks.

FEATURES

Want to take a closer look? Learn more about the product in depth by exploring its design and features.

Unique articulated steering

The unique articulated steering system allows the rear pair of wheels to swing in underneath the machine. The result is superior manoeuvrability with a minimum turning radius at full lock.

Trimming ability

The front-mounted cutting deck gives excellent overview of the working area, enabling precise, close-up trimming.

Mowing accessibility

The low profile front-mounted cutting deck gives unbeatable accessibility in under fences, bushes, park benches etc.

Compact design

The compact size together with the unique articulated steering makes it easy to manoeuvre the machine in narrow spaces and tricky areas.

• Commercial graded transmission
• Hillside driving performance
• Versatile usage
• Cabin
• All-Wheel-Drive (AWD)
• Shaft PTO
• Quick coupling
• Kubota diesel engine
• Ergonomic operation
• Hydraulic power steering
• Easy-access controls
• Easy access
• Greasable mandrels
• Off-set cutting deck
• Service position
• Durable ladder frame
• Cast iron rear wagon
• Heavy-duty deck design
• Four large wheels
• Ready for Combi deck

Commercial graded transmissionHigh-specified variable piston pumps with separate gear boxes for front and rear axle.

Specifications

 Engine

Motor/engine manufacturerKubotaEngine nameD1105Motor/engine modelDiesel horisontal axleCylinder displacement1123 cm³Cylinders3Engine coolingLiquidPower/fuel typeDieselFuel tank volume23 lEngine lubrication typePressure with OilfilterOil typeSAE10W40Oil filterYesNet power at preset rpm Energy17.8 kWExhaust emissions (CO2 EU V)1018 g/kWh

 Drive system

Transmission typeHydrostatic AWDDrive methodPedal-operatedSpeed forward max19 km/hSpeed reverse max15 km/h

 Cutting deck

Uncut circle58 cmCutting width, min132 cmCutting width, max155 cmCutting height steps7Blade engagementElectric clutchCutting height max112 mmCutting height min30 mm

 Equipment

Power steeringYesAll-Wheel Drive (AWD)YesOptional cutting decksCombi 132, Combi 155Hydraulic equipment liftYesPivoting rear axleYesSeat typeFull suspension, arm restsSeat manufacturerSEAT industriesSeat materialVinylSeat suspensionYesSeat back heightHighHinged armrestsStandardROPSStandard (foldable)Oil coolerYesService positionYesHeadlightsYesQuick connectionYesHour meter typeDigital12V outletYesCup holderNoCargo holderNo

 Dimensions

Tyre manufacturerKendaWheelbase106 cmGround clearance140 mmBase machine, length207.8 cmBase machine, width115.3 cmBase machine, height (ROPS down)133 cmBase machine, height (ROPS up)203.3 cmWeight677 kgBase machine, height133 cmGross weight towed350 kg
