Description
| Brand | Echo |
| Engine Type | 2-stroke, air-cooled, single cylinder |
| Engine Displacement (cc) | 30.5 |
| Net Rated Power Output | 1.3kW / 1.8ps |
| Start Method | Recoil |
| Ignition System | CDI |
| Start Assist System | ES-start |
| Carburettor | Diaphragm, Walbo WYG-11 |
| Spark Plug | NGK CMR7H |
| Fuel Tank Capacity (L) | 0.71 |
| Fuel / Oil Mixture | 50 : 1 |
| Fuel Consumption | 0.72l/h |
| Gear Reduction Ratio | 1 : 1.62 |
| Brush Cutter Blade | Blade capable, not included (arbour diameter for blade: 25.4mm) |
| Nylon Line Head | Speed Feed SF400, dual line |
| Line Diameter | 2.4mm |
| Line Feed | Bump |
| Rotating Direction | Counterclockwise as viewed from top |
| Shaft Type | Straight, solid |
| Outer Shaft Diameter | 25mm |
| Drive Shaft Diameter | 7mm |
| Handle Type | Cowhorn |
| Vibration – Grass Trimmer Attachment | Left handle: 3.9m/s / Right handle: 2.6m/s |
| Sound and Noise Data | Sound pressure level: 94.9dB(A) / Sound power level: 107.7dB(A) |
| CO² | 912g/kW.h |
| Assembled Dimensions | L: 1799mm x W: 646mm x H: 569mm |
| Weight (kg) | 6 |
| Warranty | Manufacturer’s – 5 years consumer, 2 years commercial (subject to registration within 30 days) |
