Description
| Brand | Echo |
| Engine Type | 2-stroke, air-cooled, single cylinder |
| Engine Displacement | 50.2cc |
| Net Rated Power Output | 2.2kW / 2.9px |
| Start Method | Recoil |
| Start Assist System | ES-start / S-start |
| Gear Reduction Ratio | 01:01.3 |
| Fuel Tank Capacity | 1.07L |
| Fuel / Oil Mixture | 50 : 1 |
| Fuel Consumption | 1.23l/h @ maximum engine power |
| Clutch | Centrifugal, 2-shoe pivot |
| Carburettor | Diaphragm, horizontal-draft |
| Spark Plug | NGK BPMR8Y |
| Brush Cutter Blade | No (arbour diameter for blade: 25.4mm) |
| Nylon Line Head | Twin nylon line / Z5 M10L / EA-X047-000332 Z5 |
| Rotating Direction | Counterclockwise as viewed from top |
| Outer Shaft Diameter | 28mm |
| Drive Shaft Diameter | 8.mm |
| Handle Type | Front: crescent loop with cushion grip / Rear: Integrated control grip with cushion |
| Vibration – Grass Trimmer Attachment | Nylon head – Left handle: 5.3m/s / Right handle: 4.0m/s |
| Sound and Noise Data | Nylon head – Sound pressure level: 97.5dB(A) / Sound power level: 110.6dB(A) |
| CO² | 825g/kW.h |
| Assembled Dimensions | L: 2824mm x W: 449mm x H: 564mm |
| Weight | 11.9kg |
| Warranty | Manufacturer’s – 5 years consumer, 2 years commercial (subject to registration within 30 days) |
